WBC2800M

Extremely wideband dual-port antenna for 20 - 7500 MHz

  • Download datasheet

    • The WBC2800M is a highly robust wideband dual port antenna effectively covering the VHF, UHF and SHF bands. It is well suited for high power electronic countermeasure and tactical communication applications, especially where a multiple antenna set-up is not possible, or antenna co-location problems may occur.

    *No payment required on checkout

    Call our Sales team

    +35894522334

    Email our Sales team

    [email protected]

    Specifications & Resources for WBC2800M

    Ideal application and market usage

    Ideal markets

    • Safety & Security
    Design Features
    Wideband
    Frequency Range
    20 - 7500 MHz
    Gain
    1 dBi
    Power Rating
    140 W
    VSWR
    < 3.5:1
    Polarisation
    Nominally vertical
    Weight
    6.1 kg
    Connector type
    N
